Applications overview
Where commercial LED displays deliver measurable impact
Start with the operating environment, then match brightness, protection, and pixel pitch for a faster indoor or outdoor specification decision.
Advertising
- Roadside media
- DOOH networks
- Transit panels
Events
- Rental staging
- Trade booths
- Conference backdrops
Venues
- Arenas
- Hospitality screens
- Wayfinding displays
Business environments
- Corporate lobbies
- Control rooms
- Showrooms
Common planning filters
- Viewing distance
- Ambient light exposure
- Ingress protection requirement
- Service access method
- Operating schedule
Products comparison
Indoor vs outdoor LED display solutions
Compare core suitability signals to define the right panel family before requesting detailed specifications.
Indoor LED displays
High-detail panels for close-view commercial interiors.
- Best for viewing distances from approximately 1.5–10 m
- Optimized for controlled lighting and weather-protected sites
- Fine pixel pitch supports detailed branding and information
- Suitable for retail, corporate lobbies, and control environments
Outdoor LED displays
Weather-ready systems for public and high-exposure environments.
- IP-rated protection for rain, dust, and seasonal temperature shifts
- High brightness for daytime readability and roadside visibility
- Built for larger viewing distances and wide-angle audience zones
- Common for façades, transport hubs, venues, and OOH advertising
Custom requirements
For non-standard dimensions, integration, and export-driven projects.
- Cabinet size, aspect ratio, and pixel pitch planning by application
- Power and data topology options, including redundancy preferences
- Mounting, service access, and structural load constraints reviewed
- Amsterdam export packaging and documentation alignment for EU delivery
Proceed with a site-specific recommendation and quote scope.
Product range
Commercial LED display catalog
Compare brochure-derived LED series in a structured format with clear use cases, key features, and expandable technical specifications.
BIM Series
BIM Plus
Proven hot-selling indoor commercial LED display with ultra-thin panels, multiple sizes, 90° rotation, and wireless connection.
Key features
- Ultra-thin & sleek
- Various sizes for staggered splicing
- L-shaped splicing
- 90° rotation
- Mixed splicing
- Wireless connection
Applications
- Retail stores
- Shopping malls
- Hotels
- Meeting rooms
- Churches
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.9 / 2.6 / 3.1 / 3.9 / 5.2
- Pixel Density (pixels/m²)
- 262144 / 147456 / 102400 / 65536 / 36864
- LED Type
- SMD
- Module Size W*H (mm)
- 512*128 / 384*128 / 256*128 / 384*96 / 288*96 / 192*96 / 320*80 / 240*80 / 160*80 / 256*64 / 192*64 / 128*64 / 192*48 / 144*48 / 96*48
BIM Series
BIM Plus-X
Award-winning X-generation indoor LED display with stable operation, flexible installation, creative splicing, and 90° rotation.
Key features
- Stable operation
- Multiple sizes
- 90° rotation
- Creative splicing
- High brightness
- Award winner
Applications
- Direct wall mounting
- Stacking
- Hanging
- Semi-indoor shop windows
- Storefronts
- Irregular staggered shapes
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.5 / 1.9 / 2.5 / 2.6 / 3.1 / 3.9 / 5.2
- Pixel Density (pixels/㎡)
- 409600 / 262144 / 160000 / 147456 / 102400 / 65536 / 36864
- LED Type
- SMD (HOB Available)
- Panel Size W*H*D (mm)
- 1000*500*42 / 750*500*42 / 250*500*42
BIM Series
BIM Plus-T
Indoor commercial dual-side display in single-side mode with flexible installation and rear maintenance.
Key features
- Unique panel design
- Twin display capable
- Excellent dissipation
- Flexible maintenance
Applications
- Indoor commercial dual-side display
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.5 / 1.9 / 2.6 / 3.9
- Pixel Density (pixels/m²)
- 409600 / 262144 / 147456 / 65536
- LED Type
- COB / SMD
BIM Series
BIM Plus-TX
Indoor commercial dual-side display in double-side mode with independent content per side and flexible maintenance.
Key features
- Unique panel design
- Twin display
- Flexible maintenance
- Wireless connection
Applications
- Indoor commercial dual-side display
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.5 / 1.9 / 2.6 / 3.9
- Pixel Density (pixels/m²)
- 409600 / 262144 / 147456 / 65536
- LED Type
- COB / SMD
BIM Series
BIM MIN
Curved small-pixel-pitch LED display with flexible modules, smooth splicing, and front/rear maintenance.
Key features
- Flexible modules
- Curved shape
- Creative splicing
- Mixed splicing
Applications
- Concave curves
- Convex curves
- Column shapes
- Indoor glasses-free 3D creativity
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.5 / 1.9 / 2.6 / 3.9
- Pixel Density (pixels/m²)
- 409600 / 262144 / 147456 / 65536
- LED Type
- SMD
BIM Series
BIM Pro
Proven 16:9 indoor fixed LED display for 2K/4K/8K walls with wireless connection and bendable modules.
Key features
- 16:9 golden ratio
- Light & thin
- Various sizes
- Wireless connection
Applications
- 2K/4K/8K indoor fixed LED walls
- Broadcasting applications
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.6 / 1.9 / 2.6 / 4
- Pixel Density (pixels/m²)
- 390625 / 255669 / 140625 / 62500
- LED Type
- SMD
BIM Series
BIM MAX
16:9 indoor commercial LED display with bigger cabinet sizes and mixed splicing compatibility with BIM Pro.
Key features
- 16:9 golden ratio
- Ultra-thin & light
- Bigger sizes
- Mixed splicing
Applications
- 2K/4K/8K indoor commercial LED walls
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.6 / 1.9 / 2.6 / 4
- Pixel Density (pixels/m²)
- 390625 / 255669 / 140625 / 62500
- LED Type
- SMD
E-Corner Series
EC1.9
90° small arc corner LED display solution for versatile indoor/outdoor, rental and fixed installation scenarios.
Key features
- 90° corner solution
- Easy maintenance
- Die-cast aluminum
- Mixed splicing
Applications
- Indoor and outdoor
- Rental installation
- Fixed installation
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.9
- Pixel Density (pixel/㎡)
- 262144
- LED Type
- SMD
E-Corner Series
EC2.6
90° small arc corner LED display solution for versatile indoor/outdoor, rental and fixed installation scenarios.
Key features
- 90° corner solution
- Easy maintenance
- Die-cast aluminum
- Mixed splicing
Applications
- Indoor and outdoor
- Rental installation
- Fixed installation
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 2.6
- Pixel Density (pixel/㎡)
- 147456
- LED Type
- SMD
E-Corner Series
EC3.9T
90° small arc corner LED display solution for versatile indoor/outdoor, rental and fixed installation scenarios.
Key features
- 90° corner solution
- High brightness
- Outdoor-ready
- Mixed splicing
Applications
- Indoor and outdoor
- Rental installation
- Fixed installation
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 3.9
- Pixel Density (pixel/㎡)
- 65536
- LED Type
- SMD
E-Corner Series
EC4.8T
90° small arc corner LED display solution for versatile indoor/outdoor, rental and fixed installation scenarios.
Key features
- 90° corner solution
- High brightness
- Outdoor-ready
- Mixed splicing
Applications
- Indoor and outdoor
- Rental installation
- Fixed installation
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 4.8
- Pixel Density (pixel/㎡)
- 43264
- LED Type
- SMD
BIM Plus-X Series
BIM Plus-X1.5
Award-winning indoor LED display for creative shape splicing and flexible installation.
Key features
- 45° bevels
- 90° rotation
- Stable operation
- Creative splicing
Applications
- Indoor LED display
- Wall mounting
- Stacking
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.5
- Pixel Density (pixel/㎡)
- 409600
BIM Plus-X Series
BIM Plus-X1.9
Award-winning indoor LED display for creative shape splicing and flexible installation.
Key features
- 45° bevels
- 90° rotation
- Stable operation
- Creative splicing
Applications
- Indoor LED display
- Wall mounting
- Stacking
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 1.9
- Pixel Density (pixel/㎡)
- 262144
BIM Plus-X Series
BIM Plus-X2.5
Award-winning indoor LED display for creative shape splicing and flexible installation.
Key features
- 45° bevels
- 90° rotation
- Stable operation
- Creative splicing
Applications
- Indoor LED display
- Wall mounting
- Stacking
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 2.5
- Pixel Density (pixel/㎡)
- 160000
BIM Plus-X Series
BIM Plus-X2.6
Award-winning indoor LED display for creative shape splicing and flexible installation.
Key features
- 45° bevels
- 90° rotation
- Stable operation
- Creative splicing
Applications
- Indoor LED display
- Wall mounting
- Stacking
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 2.6
- Pixel Density (pixel/㎡)
- 147456
BIM Plus-X Series
BIM Plus-X3.1
Award-winning indoor LED display for creative shape splicing and flexible installation.
Key features
- 45° bevels
- 90° rotation
- Stable operation
- Creative splicing
Applications
- Indoor LED display
- Wall mounting
- Stacking
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 3.1
- Pixel Density (pixel/㎡)
- 102400
BIM Plus-X Series
BIM Plus-X3.9
Award-winning indoor LED display for creative shape splicing and flexible installation.
Key features
- 45° bevels
- 90° rotation
- Stable operation
- Creative splicing
Applications
- Indoor LED display
- Wall mounting
- Stacking
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 3.9
- Pixel Density (pixel/㎡)
- 65536
BIM Plus-X Series
BIM Plus-X5.2
Award-winning indoor LED display for creative shape splicing and flexible installation.
Key features
- 45° bevels
- 90° rotation
- Stable operation
- Creative splicing
Applications
- Indoor LED display
- Wall mounting
- Stacking
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 5.2
- Pixel Density (pixel/㎡)
- 36864
Shine Pro Series
Shine Pro2.9
High-stability Outdoor Rental LED Display
Key features
- High Stability
- Fast Installation
- Convenient Maintenance
- Wind Resistance
- Curved Splicing
- Transportation Solution
Applications
- Outdoor rental LED display
- High-speed installation and labor-saving set-ups
- Hanging and stacking installation
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 2.9
- Pixel Density (pixel/㎡)
- 112896
- LED Type
- SMD
- Module Size W*H (mm)
- 250*250
- Module Resolution W*H (dot)
- 84*84
- Panel Size W*H*D (mm)
- 500*500*74/500*1000*74
- Panel Resolution W*H (dot)
- 168*168/168*336
- Panel Material
- Die-casting Aluminum
- Panel Weight (Kg)
- 8.7/14kg (single panel); 11.1/17.5Kg (panel with wind-resistant frame)
- Maximum Hanging Height (m)
- 15m (only panels); 10m (panels with wind-resistant frame)
- Brightness (cd/㎡)
- 4500
- Brightness Adjustment
- Programmable/Auto/Manual
- Viewing Angle (H/V)
- 160°/120°
- Gray Scale (bit)
- 14-16
- Refresh Rate (Hz)
- 3840
- Frame Rate (Hz)
- 50/60
- Contrast Ratio
- 6000:1
- Color Temperature (K)
- 2000～10000 (Adjustable)
- Voltage（V）
- AC 100-240
- Average Power Consumption (W/㎡)
- 188
- Maximum Power Consumption (W/㎡)
- 750
- Serviceability
- Front & rear maintenance (module); Rear maintenance (power supply)
- IP Rating
- IP65
- Lifespan (Hours)
- 100000
- Certificates
- CB/EMC/LVD/ETL/FCC/TUV Tensile test/Compression test/Wind resistance test
Shine Pro Series
Shine Pro3.9
High-stability Outdoor Rental LED Display
Key features
- High Stability
- Fast Installation
- Convenient Maintenance
- Wind Resistance
- Curved Splicing
- Transportation Solution
Applications
- Outdoor rental LED display
- High-speed installation and labor-saving set-ups
- Hanging and stacking installation
Request specifications by email
Contact our team for project-fit technical details and export-ready documentation.
Technical specifications
- Pixel Pitch (mm)
- 3.9
- Pixel Density (pixel/㎡)
- 65536
- LED Type
- SMD
- Module Size W*H (mm)
- 250*250
- Module Resolution W*H (dot)
- 64*64
- Panel Size W*H*D (mm)
- 500*500*74/500*1000*74
- Panel Resolution W*H (dot)
- 128*128/128*256
- Panel Material
- Die-casting Aluminum
- Panel Weight (Kg)
- 8.7/14kg (single panel); 11.1/17.5Kg (panel with wind-resistant frame)
- Maximum Hanging Height (m)
- 15m (only panels); 10m (panels with wind-resistant frame)
- Brightness (cd/㎡)
- 5000/4000 (Black LED)
- Brightness Adjustment
- Programmable/Auto/Manual
- Viewing Angle (H/V)
- 160°/120°
- Gray Scale (bit)
- 14-16
- Refresh Rate (Hz)
- 3840/7680
- Frame Rate (Hz)
- 50/60
- Contrast Ratio
- 5000:1
- Color Temperature (K)
- 2000～10000 (Adjustable)
- Voltage（V）
- AC 100-240
- Average Power Consumption (W/㎡)
- 180
- Maximum Power Consumption (W/㎡)
- 720
- Serviceability
- Front & rear maintenance (module); Rear maintenance (power supply)
- IP Rating
- IP65
- Lifespan (Hours)
- 100000
- Certificates
- CB/EMC/LVD/ETL/FCC/TUV Tensile test/Compression test/Wind resistance test
Need full technical detail by email?
Request specifications by emailHow it works
From enquiry to quote in four clear steps
A practical process for technical buyers who need clear specifications and dependable quote support.
-
1. Enquiry
Share your application, location, and display objectives.
-
2. Project matching
We match suitable indoor or outdoor panel options to your use case.
-
3. Specification confirmation
Pixel pitch, dimensions, brightness, and control setup are finalized.
-
4. Quote support
Receive a clear quote with lead time, logistics, and export guidance.
